Description
Von Duprin 3327AL-18 4 26D RHR Narrow Style
The Von Duprin 3327AL-18 4 26D RHR is a narrow style, finished in Satin Chrome (626/US26D). This version: Surface Vertical Rod Exit Device, with Lever Trim.
About this exit device
Exit devices (panic bars) let anyone leave with a single push on the bar, which is why building codes require them on many assembly, school and commercial egress doors. The device type sets how the door latches: a rim device latches to a strike on the frame, surface vertical rod (SVR) and concealed vertical rod (CVR) devices latch at the top and bottom of the door, and a mortise device uses a lock body set into the door edge. Outside access depends on the trim you pair with it.
Features
- Device lengths: 2' 2' (610 mm) Door size 3' 2'4" to 3' (660mm to 914 mm) door size 4' 2'8" to 4' (813 mm to 1219 mm) door size
- Device centerline from finished floor: 39 13/16" (1006mm) Center case dimensions 8 13/16" x 2 13/32" x 1 9/16" (208mm x 62mm x 40mm)
- Mechanism case dimensions: 2 1/4" x 2 1/4" (57mm x 57mm)
- Projection: Pushbar neutral – 3 13/16" (97 mm) Pushbar depressed – 3 1/16" (78 mm)
- Latch bolt: Deadlocking anti-friction top & bottom bolt 5 /8" (16mm) throw
- Door undercut: 1 /4" (7mm)
- Top & bottom latch: 4 1/2" x 2 1/8" x 1 1/2" (114mm x 54mm x 38mm)
Specifications
| Brand | Von Duprin |
|---|---|
| Model / SKU | 3327AL-18 4 26D RHR |
| Product type | Narrow Style |
| Series | 3327A Series Surface Vertical Rod Exit Device |
| Finish | Satin Chrome – BHMA 626, US26D |
| Physical Appearance | Narrow Stile Pushpad |
| Device Type | Surface Vertical Rod |
| Mechanical Function | Lever Classroom |
| Device Length | 48 In. |
| Hand | RHR |
| Dogging Options | Hex Key Dogging |
| Strike Top | 266/248L-4 |
| Strike Bottom | 304L |
| Includes Trim | Yes |
| Trim Type | Classroom Lever |
| Trim Design | 18 - Lever |
| Trim Part No. | 360L |
| Includes Cylinder(s) | No |
| Cylinder Type | 1-1/4 In. Mortise |
| Minimum Stile Size | Narrow |
| Door Material | Metal or Wood |
| Door Width | 34 In. - 48 In. |
| Door Height | 84 In. |
| Door Thickness | 1-3/4 In. |
| Fire Rated | No |
| Reversible | Yes |
Questions and answers
Do I need fire exit hardware?
Doors that are fire rated need fire exit hardware (usually marked with an F in the model number), which has no mechanical dogging. Check the label on the door and frame, or ask us.
Does it come with outside trim?
Exit devices are often sold without trim so you can choose the outside function. Check the specifications on this page or call us to match a lever, pull or cylinder trim.
Questions about fit, finish or keying? Call Security Lock Supply at (877) 202-8118.
