3701-48 Adams Rite Exit Device

Images may not represent actual product and finish.

3701-48 Adams Rite Exit Device Rim Exit Device, Fire Rated, 48", Aluminum

$553.72 $963.00
(You save $409.28)
SKU:
3701-48

Description

3701-48 Adams Rite Exit Device

  • Finish:
  • Series: 3000 Series Exit Devices
  • Type: Exit Devices
  • Sub Type: Exit Device

Rim Exit Device, Fire Rated, 48", Aluminum

Easy to install.

  • Materials: Pushbar made of extruded aluminum, clad, or anodized in a variety of finishes.
  • Handing: Specify handing and bevel if applicable. Lever Entry Trim is field reversible.
  • Pushbar Length: Standard sizes: dimensioned for 30", 36”, 42”, and 48” openings. Standard width bars can be field cut to the next smallest opening width.
  • Door Thickness: Suits 1-3/4” standard. Can be modified for thicker doors.
  • Stile Width: 3300 – Minimum 5”. Door construction may require additional stile width to meet fire ratings and provide adequate strength. 8300 - Minimum 5".
  • Projection: 2-5/8” when fully projected, 1-5/8”when dogged.
  • Dogging: Standard dogging with hex key or cylinder dogging for 8300 Series only. Electric dogging also available for 3300 and 8300 Series.
  • Fasteners: Standard self-tapping screws. Optional Sex Bolt Kits 26-0584 (two required per device). Specify finish.
  • Strikes: Made of stainless steel. Supplied with exit device. See additional information below.
  • Cylinders (available separately): See CYLINDERS for cylinder make, thumbturn and trim ring information.
  • Cylinder x Fixed Pull: (Function 03): Accepts any standard mortise cylinder with MS® cam.
  • 3080 Entry Lever (Functions 08, 09): Accepts any standard diameter mortise cylinder with MS® cam. Accommodates cylinder lengths from 1” to 1-1/4”. (Available separately).
  • Warranty: Five year limited.
