5730-PC 689 Norton Door Controls Door Closer

Images may not represent actual product and finish.

Norton

Norton 5730-PC 689 Double Lever Arm, Aluminum Painted Double Lever Arm, Push Side Door Operator, Adjustable Size 3-6, Power Cord, Aluminum Painted

$3,689.64 $5,431.00
(You save $1,741.36)
SKU:
5730-PC 689

Description

Norton 5730-PC 689 Double Lever Arm

Norton model 5730-PC 689 is a double lever arm, finished in Aluminum Painted (689/SP28). This version: Push Side Door Operator, Adjustable Size 3-6, Power Cord.

About this door closer

A door closer controls how a door closes and latches, so it shuts fully and safely after each use. Commercial closers have separate adjustments for closing speed, latching speed and backcheck, which slows the door if it is thrown open. The arm and mounting (regular, parallel or top jamb) depend on which side of the door the closer goes and whether you need hold open.

Features

  • Door Controls (interior) (exterior) swinging door(s) shall be of rack and pinion design contained within a precision cast aluminum housing.
  • Door closing force shall be adjustable to ensure adequate closing control.
  • Door closing speed shall be controlled by independent hydraulic adjustment valves in the sweep and latch range of the closing cycle.
  • Door Operator shall provide conventional door closer opening forces unless the power operator motor is activated.
  • Door Operator shall provide conventional door closing forces at all times except in the event of power outage during powered door open cycle.
  • Door Operator opening force and speed shall be adjustable by independent electronic adjustment to ensure adequate opening control per accessibility codes.
  • Door Operator shall have an adjustable hydraulic backcheck valve to cushion the door speed if door is opened violently.
  • Door Operator shall have a manual adjustment to locate both full open and full closed door positions.

Specifications

BrandNorton
Model / SKU5730-PC 689
Product typeDouble Lever Arm
Series5700 Series Operators
FinishAluminum Painted – BHMA 689, SP28
TypeSurface
TechnologyElectrohydraulic
Mounting LocationPush Side
Mounting StyleTop Jamb
Arm TypeDouble Lever Arm Regular
HandNon-Handed
Degree Swing170¼
Reveal Size2-5/8" to 6-3/4"
Cold Weather FluidYes

Questions and answers

How do I pick the arm and mounting?
Regular arm mounts on the pull side; parallel arm mounts on the push side and is common on exterior and high-traffic doors; top jamb mounts on the frame stop. Hold open and cush arms add a hold-open or a stop.

What size closer do I need?
Size depends on door width, weight and location. Many closers are adjustable across sizes; check the specifications or ask us.

Questions about fit, finish or keying? Call Security Lock Supply at (877) 202-8118.
